ASNTO AUXT600 bottle blowing machine |SNTO|AUXT600 bottle blowing machine series
TECHNICAL FEATURES
?? ?Intensive Heating Systemr Power Saving?Ecnomical Machine
?? ?Space Saving?Smart Machine?
?? ?Optional Air Recyle Use Function
??? Capable Of Connecting Filling Machine
????Preform Heating And Blowing Delay Individu-ally Controlled
| model no.型號? auxt600 | One | Three | Four | Six | Eight | Ten |
| number of cavity? | One | Three | Four | Six | Eight | Ten |
| clamping stroke? | 100 mm. | 100 mm. | 100 mm. | 100 mm. | 100 mm. | 100 mm. |
| production? | 1500pcs/hr | 3300pcs/hr | 4000pcs / hr | 5500pcs/hr | 7500pcs/hr | 14000pcs / hr |
| total power? | 22 kw | 30kw | 38 kw | 55 kw | 70 kw | 90 kw |
| the power consumption? | ≤8 kw | ≤12 kw | ≤12 kw | ≤18 kw | ≤25 kw | ≤38 kw |
| pressure for working? | 10 kg | 10 kg | 10 kg | 10 kg | 10 kg | 10 kg |
| pressure for blowing? | 30 kg | 30 kg | 30 kg | 30 kg | 30 kg | 30 kg |
| flow rate for working? | 0.8 m3 | 1.5 m | 1.5 m | 3.0 m3 | 4.0 m3 | 2.0 m3 |
| flow rate for blowing? | 0.8 m3 | 2.0 m3 | 2.0 m3 | 3.5 m3 | 4.5 m | 5.0 m3 |
| neck diameter? | 22-38 mm | 24-32 mm | 24-32 mm | 24-32 mm | 24-32 mm | 24-32 mm |
| max diameter? | 68 mm | 68 mm | 68 mm | 65 mm | 65 mm | 65 mm |
| max height? | 240 mm | 240 mm | 240 mm | 240 mm | 230 mm | 230 mm |
| machine size LxWxH? | 2.2x1.7x1.7 m | 3.5x1.8x2 | 2.3x2.1x2.1 m | 2.6x2.2x2.2 m | 3.8x2.2x2.2 m | 5.1x2.2x2.2 m |
| auto loader LxWxH? | 1.7x1.7x2.7 m | 1.7x2.7x2.7 m | 1.7x2.7x2.7 m | 1.7x2.7x2.7 | 1.7x2.7x2.7 | 1.7x2.7x2.7 |
| machine weight? | 1800 kg. | 2000kg | 2200 kg | 2800 kg | 3500 kg. | 6000 kg |
